Step-by-Step Guide - Creating Azure Web App CI/CD with Terraform and Azure DevOps

Published: (6 min read)  at 07:30 PM

🌟 Setting Up CI/CD Pipeline for Azure Web App using Terraform and Azure DevOps 🌟


🚀 Introduction

In today’s fast-paced development environment, implementing Continuous Integration and Continuous Deployment (CI/CD) is crucial for efficient software delivery. In this tutorial, we will walk through the process of setting up a CI/CD pipeline for an Azure web app using Terraform and Azure DevOps. By following these steps, you can automate the deployment process and ensure high-quality code reaches your production environment.

📋 Prerequisites

Before we begin, make sure you have the following prerequisites in place:

🏗️ Step 1: Creating Infrastructure with Terraform

To ensure a consistent and repeatable infrastructure setup, we will use Terraform. Terraform allows us to define our infrastructure as code and manage it through version control. Follow these steps to create the necessary infrastructure for your Azure web app:

  1. Set up a new Azure DevOps project.
  2. Create a new repository within your project and clone it to your local machine.
  3. Create a folder structure for your Terraform code, such as infra/environment1 and infra/environment2 for two environments.
  4. Within each environment folder, create a file and define the necessary Azure resources, such as resource groups, app services, and databases. Use Terraform modules to ensure a modular and reusable infrastructure setup.
  5. Define input variables in a separate file to make your infrastructure code dynamic and easily configurable.
  6. Initialize Terraform within each environment folder by running the terraform init command. This will download the required providers and modules.
  7. Create a build pipeline in Azure DevOps to trigger the Terraform deployment. Use the “Terraform CLI” task to execute Terraform commands, passing the appropriate input variables for each environment.

🔄 Step 2: CI Steps

In this step, we will set up Continuous Integration (CI) to ensure code quality and generate artifacts for deployment.

  1. Configure your source code repository in Azure DevOps to trigger the CI pipeline on code changes.
  2. Set up a build pipeline in Azure DevOps with the following steps:
    • Use a task to install the required dependencies for your application, such as Python packages.
    • Run unit tests using your preferred testing framework (e.g., pytest) to ensure code functionality.
    • Use linters (flake8, black) and formatters (isort) to enforce code style consistency.
    • Generate a code coverage report using to track the percentage of code covered by tests.
    • Integrate with SonarQube for static code analysis and maintain code quality.
    • Build a Docker image containing your application code and dependencies.
    • Push the Docker image to an Azure Container Registry (ACR) for later use in deployment.

🚀 Step 3: CD — Continuous Deployment

Now that we have our infrastructure in place and a reliable CI process, we can proceed to set up Continuous Deployment (CD) to automate the deployment process.

  1. Determine the deployment strategy based on your requirements. For example:
    • Two environments (dev and prod) can follow a simple deployment flow where the code is deployed to dev first and then promoted to prod after successful testing.
    • Three environments (dev, test, and prod) can follow a more complex deployment flow where code moves through each environment sequentially.
  2. Create release pipelines in Azure DevOps for each environment, using the appropriate deployment strategy.
  3. Configure post-deployment tests specific to each environment to ensure the deployed application is functioning as expected.
  4. Add performance testing steps after the deployment to the dev environment to validate system performance under real-world conditions. Use tools like Apache JMeter or Azure Application Insights to conduct performance tests.

🛠️ Code Snippets

Step 1: Creating Infrastructure with Terraform

  1. Set up Azure DevOps pipeline:

    • Create a new pipeline in Azure DevOps and select your repository.
    • Choose the appropriate trigger for your pipeline, such as a repository branch or pull request.
  2. Configure Terraform backend:

    • Create an Azure Storage Account to store Terraform state.
    • Add the following code to your file within each environment folder:
    terraform {
      backend "azurerm" {
        storage_account_name = "<storage_account_name>"
        container_name       = "<container_name>"
        key                  = "<environment>.tfstate"
  3. Define variables:

    • Create a file within each environment folder to define input variables. Here’s an example:
    variable "resource_group_name" {
      description = "Name of the resource group"
      type        = string
  4. Create infrastructure resources:

    • Add the following code to create a resource group and app service plan in the file within each environment folder:
    resource "azurerm_resource_group" "example" {
      name     = var.resource_group_name
      location = "West Europe"
    resource "azurerm_app_service_plan" "example" {
      name                = "example-appserviceplan"
      location            = azurerm_resource_group.example.location
      resource_group_name =
      sku {
        tier = "Standard"
        size = "S1"
  5. Execute Terraform commands in Azure DevOps pipeline:

    • Add the following steps to your Azure DevOps pipeline YAML file:
      - main
      vmImage: "ubuntu-latest"
      - task: TerraformInstaller@0
          terraformVersion: "0.15.4"
      - script: |
          terraform init
          terraform apply -auto-approve
        workingDirectory: "infra/environment1"

Step 2: CI Steps

  1. Configure CI pipeline triggers and variables:

    • Define your pipeline triggers and variables in the Azure DevOps YAML file, as per your requirements.
  2. Set up build steps:

    • Use appropriate task names and commands based on your specific needs. Here’s an example:
      - main
      vmImage: "ubuntu-latest"
      - script: pip install -r requirements.txt
        displayName: "Install dependencies"
      - script: pytest
        displayName: "Run tests"
      - script: flake8 .
        displayName: "Lint code"
      - script: coverage run -m pytest
        displayName: "Run coverage"
      - task: SonarQubePrepare@4
          SonarQube: "SonarQube"
          scannerMode: "CLI"
          configMode: "file"
          configFile: ""
      - task: SonarQubeAnalyze@4
      - task: SonarQubePublish@4
  3. Build and push Docker image:

    • Use the appropriate task names and commands based on your specific needs. Here’s an example:
      - task: Docker@2
          containerRegistry: "MyACR"
          repository: "myapp"
          command: "buildAndPush"
          Dockerfile: "**/Dockerfile"
          tags: "$(Build.BuildId)"

Step 3: CD — Continuous Deployment

  1. Determine deployment strategy and set up release pipelines:

    • Based on your deployment strategy, define the release pipelines in Azure DevOps with appropriate stages and triggers.
  2. Configure post-deployment tests:

    • Use the appropriate tasks and scripts to run post-deployment tests. Here’s an example:
    - task: PythonScript@0
        scriptSource: "filePath"
        scriptPath: "scripts/"
        arguments: "-e $(environment)"
    - task: PublishTestResults@2
        testResultsFormat: "JUnit"
        testResultsFiles: "**/test-results.xml"
        searchFolder: "$(System.DefaultWorkingDirectory)"
  3. Perform performance testing:

    • Use the appropriate tasks and scripts to perform performance testing. Here’s an example using Apache JMeter:
    - task: DownloadFile@1
        sourceUrl: ""
        targetPath: "$(Pipeline.Workspace)/jmeter/apache-jmeter-5.4.1.tgz"
    - task: ExtractFiles@1
        archiveFilePatterns: "$(Pipeline.Workspace)/jmeter/apache-jmeter-5.4.1.tgz"
        destinationFolder: "$(Pipeline.Workspace)/jmeter/"
    - task: CmdLine@2
        script: |
          $(Pipeline.Workspace)/jmeter/apache-jmeter-5.4.1/bin/jmeter -n -t $(Pipeline.Workspace)/jmeter/performance_test.jmx -l $(Pipeline.Workspace)/jmeter/results.jtl

Note: The provided code snippets serve as examples and may require modifications based on your specific application, environment, and tools being used. Remember to update the connection names, resource names, and specific command arguments according to your project setup and requirements.
